B.E. Electronics & Communication Engineering

Facilities

Lab Facilities

To cope with recent trends, the laboratories have equipped with advanced softwares like VLSI Design Development Tool (Xilinx 9.1i), MATLAB 7.0, TMS320C50 Universal Debugger, ORCAD PSPICE, Network Simulation Software etc.

Optical and Microwave Lab

The lab is equipped with various types of antennas and study about the radiation patterns and other parameters of different antennas. It also consists of RF Circuit design such as oscillators like Colpitts, Hartley, RF filter, RF mixer, Modulation and Demodulation kits for the study of experiments. It also helps the students to study about the measurement of numerical aperture, attenuation and various loss measurements in optical fibers.

Description of the Equipments	Quantity available
Klystron power supply	4
Klystron tube	3
Gunn power supply	3
Gunn oscillator	3
PIN modulator	3
Isolator	5
Attenuator	5
Frequency meter	5
Slotted section	5
Detector mount	5
Termination	10
Movable short	5
Slide screw tuner	4
Horn antenna	2
Magic TEE	2
E-Plane TEE	2
H-Plane TEE	2
Directional coupler	2
VSWR meter	4
Power meter	2
Universal Waveguide stand	25
Optical power source	5
Fiber Optic Power meter	2
fiber optic trainer Kit	5
Multiplexer / Demultiplexer Kit	2
Laser Trainer Kit	2
PIN Diode	3
Digital Storage Oscilloscope	9

Communication Systems Lab

This lab is equipped with Trainer kits to study Amplitude, Frequency and Pulse modulation Techniques. The students are exposed to the sampling Techniques using the trainer kit available in the lab. The students are trained in MATLAB for simulation and analysis of various modulation schemes.

Description of the Equipments	Quantity available
Function Generator (1 MHz )	15
Power Supply ( 0 - 30 Volts Variable )( IC Power supply)	15
Bread Board	10
AM Transceiver Kit	2
FM Transceiver Kit	2
PAM,PPM,PWM Trainer Kits	2
PCM /DM/ ADM Trainer Kit	2
ASK,PSK,FSK,QPSK Trainer Kits	2
Mat lab (Communication tool box)	5
PLL frequency multiplier	2
Pre-emphasis and De-emphasis	2
Balanced Modulator	2

Networks Laboratory

The lab is fully equipped with Network Lab Trainer and latest software Vi-Rt Sim. Using this software, Encryption & Decryption of files, Wireless LAN transfer of files can be implemented. Routing Algorithms can also be analyzed for shortest path identification.

Description of the Equipments	Quantity available
Personal Computer (with recent specification)	32
Ethernet LAN trainer	3
Network Simulator Software/ ViRt Sim	32
C. Complier	32
Java	32

Digital Laboratory

The Digital lab is well equipped with digital lab trainer to analyze the design of combinational and sequential circuits. The Lab has an excellent collection of basic components in all ranges for conducting practical.

Description of the Equipments	Quantity available
Digital IC Trainer Kit	30
Digital IC Tester	3
Personal Computer (Core 2duo processor with 2 Gb RAM) with PSPICE Software	2

Linear Integrated Circuits Laboratory

The lab is fully-fledged which principally focuses on design of amplifiers, oscillators, filters, etc using the basic operational amplifier IC 741.This laboratory guides the students and gives exposure to innovative ideas using software Orcad PSPICE. The Lab has an excellent collection of basic components in all ranges for conducting practical.

Description of the Equipments	Quantity available
Dual, (0-30V) variable Power Supply	10
CRO 30MHz	9
Function Generator   1 MHz	8
IC Tester (Analog)	2
Bread board	10
Computer (PSPICE installed)	1

Electronics Circuits Laboratory

The Electronics Circuits lab is fully-fledged which principally focuses on concepts of resonance phenomenon, transients, coupled circuits, turned circuits and also on the VI characteristics of various electronic devices like FET, BJT etc. The Lab has an excellent collection of basic components in all ranges for conducting practical. A 10 Cathode Ray Oscilloscope of different MHz range is available in the lab.

Description of the Equipments	Quantity available
Variable DC Power Supply (0-30V)	8
Fixed Power Supply (+ / - 12)V	6
CRO  30MHz	10
Multimeter Digital	6
Function Generator 1 MHz	8
DC Ammeter	10
DC Voltmeter	10
Digital LCR Meter	1
PC with SPICE Simulation Software	6

Electronic System Design Lab

The lab is equipped with PLL, PCB layout design using CAD ,DSP based system design by using TMS320C50 Processor, Micro Controller based system design, Design of AC/ DC Voltage regulator using SCR, Design of instrumentation amplifiers, process control timer, design of wireless data modem ,design of AM & FM modulator and demodulator, Design of Arithmetic Logic unit and Psuedo-random sequence Generator.

Microprocessor and Microcontroller Lab

The lab consists of 8085, 8086 Processor and 8051 Microcontroller Trainer Kit and its Interfacing Peripherals, Traffic Light Controller, Stepper Motor Control and AC & DC Motor Control.

Description of the Equipments	Quantity available
8085 Trainer	15
8086 Trainer	15
8051 Trainer	15
8255 Interfacing Card	5
8279 Interfacing Card	5
8251 Interfacing Card	5
ADC Interfacing card	5
DAC Interfacing Card	5
Stepper motor Interfacing card	5

VLSI Laboratory

The VLSI lab is endured with latest software Xilinx ISE 9.1i. The students are trained in this software for the designing of combinational & sequential circuits and simulation, analysis of various Complex Digital circuits. FPGA- SPARTAN 3E kit is also used for Design& Implementation of traffic light controller and Real time clock.

Description of Equipment	Quantity available
PC(With Recent Specification)	30
List of software a) Simulator and Synthesizer  tool with down loader (VHDL/Verilog) b) Transistor level Spice modeling tool	15 User license each
No. of FPGA kits a) I/O cards b) Add on cards for FPGA	15

Digital Signal Processing Laboratory

This Lab is equipped with Digital Signal Processor TMS 320C5X for study of various signal-processing experiments. The different sorts of Audio Signal Processing are experimented with various Filter Designs in this Lab. The students are exposed to the Debugging Techniques using the DSP Processors Debuggers available in the lab. The students are trained in MATLAB for simulation and analysis of various complex signal models.

Description of Equipment	Quantity required
PCs with Fixed / Floating point DSP Processors (Kit /  Add-on Cards)/ 6713 advanced kit	15 Units (2 students per system)
List of software required: MATLAB with Simulink and Signal Processing Tool Box	15 Users license
Function Generators (1MHz)	15
CRO (30MHz)	15
